Eco Max XL Connected

Eco Max XL Connected with Glass Back and Seated Height Table

Eco Max XL Connected

Patent Pending

American Made

The Ultimate Modular Boardroom

The Eco Max XL Connected is the largest and most capable meeting environment in the entire collection. By linking two Eco Max XL units into one unified space, this configuration creates a massive acoustic suite designed to comfortably accommodate 10 to 11 people. It offers the scale and presence of a traditional boardroom, ideal for all-hands meetings, leadership summits, or large-scale workshops, without the permanence or cost of construction.

Uniquely engineered for unity, the connected design features a seamless, floor-free interior that removes physical barriers between the units, ensuring a smooth, accessible surface throughout. Despite its expansive footprint, it maintains 30.2 dB speech level reduction (Class A), ensuring that sensitive executive discussions remain secure. The internal climate is managed by a synchronized high-capacity ventilation system, ensuring fresh air reaches every corner of the extended suite.

IBCCES Certified Autism Resource


Eco Max XL Connected with Glass Back
Eco Max XL Connected with Glass Back
Eco Max XL Connected with Glass Back and Seated Height Table
Eco Max XL Connected with Glass Back and Seated Height Table
Eco Max XL Connected with Upholstered Back
Eco Max XL Connected with Upholstered Back

Centralized Intelligence & Infinite Configuration

The Eco Max XL Connected is designed to function as a high-tech strategy hub. A specialized deep center column bridges the two units, providing the ideal housing for integrated power outlets and a wall mount for a large presentation screen, turning the center of the room into a focal point for hybrid collaboration. A single ceiling-mounted motion sensor intelligently manages the LED lighting and ventilation across the entire suite, maximizing energy efficiency.

Flexibility is paramount in this design. The generous interior allows for a long central conference table, dual workstations, or a mix of sofas and chairs for a lounge feel. For high-traffic environments, the pod offers the option of a second rear door, allowing for dual-sided entry or a pass-through configuration. Crafted from circular materials like recycled wood and textiles, the Eco Max XL Connected delivers executive-level performance with a sustainable footprint.

Eco Max XL Connected with Seated Height Tables
Eco Max XL Connected with Seated Height Tables
Technical drawings of the Eco Max XL Connected Pod with measurements.

Exterior Dimensions

Width: 166.3″
Depth: 177.2″
Height: 91.9″
Door Width: 36.1″

Interior Dimensions

Width: 157.8″
Depth: 172.8″
Height: 88″

Technical drawings of the Eco Max XL Connected Pod with measurements.

Exterior Dimensions

Width: 166.3″
Depth: 177.2″
Height: 91.9″
Door Width: 36.1″

Interior Dimensions

Width: 157.8″
Depth: 172.8″
Height: 88″

Resources

Our Acoustic Reports, CAD & SketchUp Files, Eco Passports, and Spec Sheets embody our commitment to simplicity, adaptability, and sustainability. Ideal for architects, designers, and innovators championing green projects.

Options

Shelf Low
Shelf Low
Column Table
Column Table
Magnetic White Board
Magnetic White Board
LCD Screen Mounting
LCD Screen Mounting
XL Sofa
XL Sofa
